Key Features
- Model: A302R
- Data Rate: Up to 300Mbps (2.4GHz), Up to 867Mbps (5Ghz)
- Number of Antenna: 2 x 2.4GHz, 2 x 5GHz (5dBi)
- Interface: 4x LAN, 1x WAN
- IPV6 Support, MU-MIMO, Beamforming Technology
Specification
| Network & Wireless | |
| Wireless Frequency | 1200Mbps |
| Security | MAC Filtering <br> IP/Port Filtering <br> URL Filtering<br> |
| WAN Interface | Static IP, DHCP, PPPoE/Russia PPPoE, PPTP/Russia PPTP, L2TP/Russia L2TP |
| Antenna | 4 x Internal Antennas<br> |
| Button | 1 *Mesh/RST Button<br> |
| Network Standard | IEEE 802.11ax<br> IEEE 802.11ac <br> IEEE 802.11n<br> IEEE 802.11g<br> IEEE 802.11b<br> IEEE 802.11a<br> |
| Frequency | 2.4~2.4835GHz<br> 5.18~5.825GHz<br> |
| Operating Temperature | 0℃~40 ℃ (32 ℉~104℉) |
| Storage Humidity | 10%~90% non-condensing |
| Storage Temperature | -40℃~70 ℃ (-40 ℉~158℉) |
| Data Rate | 2.4GHz: Up to 574Mbps(2*2 40MHz)<br> 5GHz: Up to 2402Mbps(2*2 160MHz)<br> |
| Power | |
| Power Mode | 12V DC/1A |
| Connectors | |
| LAN | 4 (10/100) |
| Others | |
| Special Feature | – Complies with the IEEE 802.11ac Wave 2 Wi-Fi standard.<br> – 1167Mbps in total on dual band, 867Mbps on 5GHz and 300Mbps on 2.4GHz.<br> – MU-MIMO technology allows to transfer data to multiple devices at the same time, each device enjoys high Internet speed separately.<br> – Beamforming technology allows to intensively transmit the signal to the directions of the other wireless connected terminals, improving the using-efficiency of the bandwidth and reducing the dead spots and the surrounding unnecessary RF interference.<br> – Full gigabit ports offers a larger capability for data streaming via cable connection.<br> – Supports DHCP, Static IP, PPPoE, PPTP and L2TP connection mode.<br> – Provides 64/128-bit WEP, WPA, and WPA2 encryption.<br> – QoS function allows to change the bandwidth for different terminals via IP address.<br> – Supports IP address filtering, port filtering, MAC filtering, URL filtering and port forwarding.<br> – Multiple SSIDs allows to create different SSIDs for different groups, better for Internet access management.<br> – Smart UI design is easy for the users to finish the basic configuration with their cellphones. |
| Physical Specification | |
| Colors | Black |
| Dimensions (W x D x H) | 206*121*41mm（excluding antennas） |
| Weight | 360 g (0.8 lb) |
| Warranty Information | |
| Warranty | 1 Year |
